What is a full knuckled boom crane?
A full knuckled boom crane is a lifting equipment with multiple foldable boom sections connected by joints. It can flexibly bend and extend to perform complex lifting and handling operations. Featuring a compact multi-joint boom design, it achieves the maximum working range within limited deck space and can complete lifting tasks at complex angles without the need for additional support structures.
The crane primarily consists of a vertical support column (including its base and tower sections), multiple articulated arms, a hoisting mechanism, a slewing mechanism, and a luffing mechanism. The boom sections are connected by joints, enabling bending at various angles and enhancing operational flexibility.
Working Principle
A hydraulic system powers the full knuckled boom crane.
The telescoping of hydraulic cylinders is controlled to realize the bending and extension of boom sections, thereby achieving the lifting, lowering, and movement of goods.
The crane's tower body can generally rotate 0 ° to 360 °, and when coordinated with the movement of the boom sections, it enables precise positioning and handling of goods within a wide working range.
Core Advantages of full knuckled boom crane
Precise Controllability : The multi-joint design enables flexible operation around obstacles, achieving intelligent lifting that bypasses rather than crosses barriers.
Intuitive Human-Machine Interface: A control system that complies with maritime operational habits reduces training time and operational errors.
All-Weather Operation Capability: The sealed electro-hydraulic system and anti-corrosion coating ensure stable operation in harsh environments with salt spray and high humidity.
Safety-Priority Design: Multiple overload protection and emergency stop systems ensure the safety of personnel and cargo.
Space Optimization: The folded footprint is reduced by more than 40%, maximizing available deck space.
Simplified Maintenance: The modular design enables quick on-site replacement of key components, minimizing vessel downtime.
Durable Structure: Marine-grade steel and special anti-corrosion treatment are employed to withstand long-term offshore service conditions.
Configuration Flexibility: Multiple load configurations, ranging from 0.5 to 50 tons, are available, adapting to various types of vessels and operational requirements.
Classification Society Certifications: CCS, DNV-GL, ABS, RS, RINA, NK, KR, BV, etc.
Technical Support and Spare Parts Supply
full knuckled boom crane Design details
--- for the special environment at sea
Corrosion protection
- Triple anti-corrosion coating system (epoxy primer, zinc interlayer, polyurethane topcoat)
- Stainless steel fasteners with hydraulic joints
- IP66 protection level for electrical components, IP67 rating for key controllers
- Additional protection is provided for key hydraulic and electrical interfaces.
Exercise compensation ability
- Optional wave compensation system to keep the load stable when the ship shakes
Environmental adaptability
- Operating temperature range: -50°C to +55°C
- Adapt to wind speed: 20m/s in working condition, 35m/s in survival state
application of full knuckled boom crane
Ship material supply: Efficiently complete cargo transfer within limited deck space
Offshore engineering support: Assist in equipment installation and maintenance operations
Maritime rescue operations: Precise control capabilities are suitable for rescue equipment delivery
Deployment of scientific research equipment: smooth operation and protection of precision instruments
Port Handling Assistance: As a marine handling equipment, it reduces dependence on external resources
Technical Specification of full knuckled boom crane
- SWL: 2500kg
- Max. lifting copacity: 19.5T.m
- Max. working radius: 8m
- Power: 15KW
- Output: 40L/min
- Working pressure: 25MPa
- Oil tank volume: 130L
- Rotation angle: 410°
- Weight: ~2100kg
- Mount space: 1095mm
- Folding arm structure: 3-5 hydraulically driven arm segments for maximum flexibility
- Swivel system: 360° continuous rotation with automatic braking
- Control system: dual operating positions (local + remote control optional), viewing angle coverage without blind spots
- Safety system: load torque limiter, hydraulic explosion-proof valve, emergency manual recovery device
Our Commitment
With over 10 years of dedicated focus on the design and manufacturing of Full Knuckled Boom Cranes, we possess an in-depth understanding of the practical demands of maritime operations. What we provide is not merely equipment, but comprehensive maritime lifting solutions. Every crane undergoes no-load, load, and overload testing before delivery and comes with a 2-year warranty, ensuring reliable performance from the moment of handover.
For a customized configuration plan tailored to your vessel type, please don't hesitate to contact our maritime equipment consultants. We can deliver the most cost-effective solutions tailored to your vessel's dimensions, typical operating types, and budget range.
